MICROMATIC.COM | 866-327-4159 POWER PACK SERVICE MANUAL | 5
EQUIPMENT SPECIFICATIONS
MODEL MMPP4303-PKG-WC MMPP4303-PKG-3 MMPP4303-PKG-3-WC MMPP4305-PKG MMPP4305-PKG-WC
Type Water Cooled* Air Cooled Water Cooled* Air Cooled Water Cooled*
BTUs* 5,100 5,100 5,100 7,250 7,250
Compressor HP 3/4 3/4 3/4 1 1
Glycol Pumps 2 3 3 2 2
Pump Type
Rotary Vane Rotary Vane Rotary Vane Rotary Vane Rotary Vane
Pump GPH
80 80 80 80 80
Pump Motor HP
1/3 1/3 1/3 1/3 1/3
Pump Inlet/Outlet Barbs 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8")
Plug Type
6-15P 6-20P 6-20P 6-15P 6-15P
Voltage
208/230 208/230 208/230 208/230 208/230
Amps (Running) 8.4A 11A 9.9A 11.0A 9.5A
Refrigerant R134a R134a R134a R134a R134a
Charge (oz.)
0.51 kg (18 oz) 0.79 kg (28 oz) 0.51 kg (18 oz) 0.56 kg (20 oz) 0.56 kg (20 oz)
Refrigerant
Running Pressures
18 (low)
140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
Dimensions
L x W x H Including
pump(s) and motor(s)
30" x 18" x 28.75" 30" x 18" x 29.75" 30" x 18" x 28.75" 37.12" x 18.75" x 31.15" 37.12” x 18.75” x 31.5”
Weight (lbs) 80 kg / 175 lbs 91 kg / 200 lbs 80 kg / 175 lbs 98 kg / 215 lbs 98 kg / 215 lbs
Bath Capacity (gal) 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L
Bath Insulation
Thickness
1.5" 1.5" 1.5" 1.5" 1.5"
Inlet Water Pressure
Min 40 psi
Max 120 psi
NA
Min 40 psi
Max 120 psi
NA
Min 40 psi
Max 120 psi
Water Inlet & Outlet Fitting 9.52mm (3/8") NA 9.52mm (3/8") NA 9.52mm (3/8")
Minimum Water Pipe Size 3/8" NA 3/8" NA 3/8"
Approval
ETL Listed ETL Listed ETL Listed ETL Listed ETL Listed
*Rated at 20° F evaporator temperature and 90° F ambient temperature. †.3GPM, water is only used when the temperature of the condenser rises high enough to
open the cooling inlet valve. This is approximately 40% of the operating time depending on the ambient temperature and usage. Condenser Inlet Water Temperature:
Minimum 45° F / Maximum 80° F
