6 - HARDWARE SPECIFICATIONS
POWER INPUT
INPUT POWER 500 VA max. IEC 60320, C14 (E) socket, filtered
LINE VOLTAGE 90-130 VAC / 215-245 VAC, internally switchable
FREQUENCY 50/60 Hz
FUSE 5x20 mm, T, 3.15 A/250 V for 230 VAC INPUT, 6.3 A/250 V for 115 VAC INPUT
ROTATOR
MOTOR OUTPUT 4x isolated PWM output, max. 48 V, max. 7 A
SENSOR INPUT 0-9 V, max. 16 kHz
REFERENCE OUTPUT 9 V, max. 18 mA (shorted)
SENSOR ADC RESOLUTION 2x 12 bit, 64x oversampling, 10 bit DAC for offset control
D-SENSOR 4x RS-485, 1x 0-10 V analog output, 1x 12 VDC, 0.5 A auxiliary output
LINK CAN bus
COMPUTER
USB B USB 2.0, full speed, CDC compliance
USB A USB 2.0, full speed, mass storage, keyboard HID support
Ethernet IEEE 802.3, 100BaseTX, auto MDI/MDIX
SERIAL RS-232
GENERAL
DIMENSIONS W: 265 mm D: 150 mm H 125 mm
WEIGHT 2.85 kg net
