microHAM ARCO User Manual

microHAM © 2021 All rights reserved
APPENDIX B – ROTATOR SETTINGS & CONNECTIONS
BRAND: Yaesu
TYPE: G-650C, G-800(any), G-1000(any), G-2700(any), G-2800(any), G-5500DC (AZ part)
Factory cable connects rectangular ROTATOR (10) connector
BRAND: Yaesu
TYPE: G-450C (G-450ADC, G-450CDC)
Factory cable connects rectangular ROTATOR (10) connector
BRAND: Yaesu
TYPE: G-400
30
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CW 4 MOTOR A 6
CCW 5 MOTOR C 4
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR DC (reversible)
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC
POWER 24 V
BRAKE NO
TOTAL ROTATION 370
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
WIPER 2 SENSOR HI 3
POT LO 3 SENSOR LO 1
CW 4 MOTOR A 6
CCW 5 MOTOR C 4
If you are using rectangular connector (10) for rotator
connection, short pins 2 + 3 together on green ARCO
rotator terminal.
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR DC (reversible)
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES YES
