BRAND: Yaesu
TYPE: G-400RC
BRAND: Yaesu
TYPE: G-450A
Factory cable connects rectangular ROTATOR (10) connector
BRAND: Yaesu
TYPE: G-450XL
31
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
WIPER 2 SENSOR HI 3
POT LO 3 SENSOR LO 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR AC
POWER 24 V
BRAKE NO
TOTAL ROTATION 370
LIMIT SWITCHES NO
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CCW 4 MOTOR A 6
CW 5 MOTOR C 4
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC+CAP
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES NO
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
WIPER 2 SENSOR HI 3
POT LO 3 SENSOR LO 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR AC+CAP
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES NO
