microHAM ARCO User Manual

microHAM © 2021 All rights reserved
BRAND: Yaesu
TYPE: G-650A
Factory cable connects rectangular ROTATOR (10) connector
BRAND: Yaesu
TYPE: G5500 (AZ part)
BRAND: Yaesu
TYPE: G-600
32
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
LS CCW/POT LO 3 MOTOR D + SENSOR LO 5 + 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
LS CW 6 MOTOR B 7
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC
POWER 24 V
BRAKE NO
TOTAL ROTATION 360
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CCW 4 MOTOR A 6
CW 5 MOTOR C 4
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC+CAP
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
COM 6 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC+CAP
POWER 24 V
BRAKE NO
TOTAL ROTATION 450
LIMIT SWITCHES YES
