microHAM ARCO User Manual

microHAM © 2021 All rights reserved
BRAND: Yaesu
TYPE: G-600RC
BRAND: Yaesu
TYPE: G-2000RC
BRAND: TIC General
TYPE: 1022, 1032, 1048
33
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
WIPER 2 SENSOR HI 3
POT LO 3 SENSOR LO 1
CCW 4 MOTOR C 4
CW 5 MOTOR A 6
LS CW 6 MOTOR B 7
LS CCW 7 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR AC
POWER 24 V
BRAKE NO
TOTAL ROTATION 360
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
WIPER 1 SENSOR HI 3
POT LO 2 SENSOR LO 1
CCW 3 MOTOR C 4
CW 4 MOTOR A 6
LS CCW 5 MOTOR D 5
LS CW 6 MOTOR D 5
BRAKE 7 MOTOR B 7
BRAKE COM 8 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR AC
POWER 24 V
BRAKE YES
TOTAL ROTATION 370
LIMIT SWITCHES NO
Due to rotator internal wiring, limit
switches must be bypassed.
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 2 MOTOR A + B 6 + 7
CCW 3 MOTOR C + D 4 + 5
POT HI 4 SENSOR HI 3
WIPER 5 SENSOR C 2
POT LO 6 SENSOR LO 1
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR DC (reversible)
POWER 24 V
BRAKE NO
TOTAL ROTATION 400
LIMIT SWITCHES NO
