microHAM ARCO User Manual

microHAM © 2021 All rights reserved
BRAND: Create
TYPE: RC5x
BRAND: M2 Antenna Systems
TYPE: OR2800G2
BRAND: Hy-Gain
TYPE: HAM xx, T2xx.
34
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
COM 1 MOTOR D + LSW CCW 5 + 8
CW 2 MOTOR A 6
CCW 3 MOTOR C 4
POT LO 4 SENSOR LO 1
WIPER 5 SENSOR C 2
POT HI 6 SENSOR HI 3
LS 7 LSW CW 9
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 1 kΩ or 5 kΩ
MOTOR AC+CAP
POWER 24 V
BRAKE NO
TOTAL ROTATION 370
LIMIT SWITCHES YES
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
COM/WIPER 1 MOTOR D + SENSOR LO 5 + 1
BRAKE 2 MOTOR B 7
POT HI 3 SENSOR HI 3*
CCW 4 MOTOR C 4
LS CW 5 LSW CW 9
LS CCW 6 LSW CCW 8
CW 8 MOTOR A 6
* Add supplied 330Ω resistor in series for improved
accuracy in first CCW quarter circle. Optional adapter
already includes series resistor.
Rotator tab settings:
PARAMETER VALUE
SENSOR RHEO 500 Ω
MOTOR AC
POWER 24 V
BRAKE YES
TOTAL ROTATION 360
LIMIT SWITCHES YES
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A + B 6 + 7
CCW 2 MOTOR C + D 4 + 5
REED B 3 SENSOR LO 1
REED A 4 SENSOR C + HI 2 + 3
Rotator tab settings:
PARAMETER VALUE
SENSOR REED
P/360º 3960
MOTOR DC (reversible)
POWER 48 V
BRAKE NO
TOTAL ROTATION 388
LIMIT SWITCHES YES

microHAM ARCO Specifications

General

Brand	microHAM
Model	ARCO
Category	Controller
Language	English
