microHAM ARCO User Manual

microHAM © 2021 All rights reserved
BRAND: Daiwa
TYPE: MR-300E, 750E/PE
BRAND: K7NV
TYPE: Prop Pitch S, M, L, XL
BRAND: Prosistel
TYPE: D series PST-641, PST-2051, PST-61
35
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
POT HI 1 SENSOR HI 3
WIPER 2 SENSOR C 2
POT LO 3 SENSOR LO 1
CCW 5 MOTOR C 4
CW 6 MOTOR A 6
COM 7 MOTOR D 5
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 500 Ω
MOTOR AC+CAP
POWER 24 V
BRAKE YES*
TOTAL ROTATION 365
LIMIT SWITCHES NO
* Internal auto-brake
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
REED B 1 SENSOR LO 1
REED A 2 SENSOR C + HI 2 + 3
CW 3 MOTOR A + B 6 + 7
CCW 4 MOTOR C + D 4 + 5
COM 5 NEG COM 10
Rotator tab settings:
PARAMETER VALUE
SENSOR REED
P/360º *
MOTOR DC+COM
POWER 24 V
BRAKE NO
TOTAL ROTATION 360
LIMIT SWITCHES NO
* S=9576, M=7063, L=7056
XL=7497/5920
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A + B 6 + 7
CCW 2 MOTOR C + D 4 + 5
WIPER 3 SENSOR C 2
POT HI 4 SENSOR HI 3
POT LO 5 SENSOR LO 1
Rotator tab settings:
PARAMETER VALUE
SENSOR M-TURN POT 10 kΩ
MOTOR DC (reversible)
POWER 12 V
BRAKE NO
TOTAL ROTATION 500
LIMIT SWITCHES NO
