microHAM ARCO User Manual

microHAM © 2021 All rights reserved
BRAND: Prosistel
TYPE: D series PST-71, PST-110
BRAND: Prosistel
TYPE: PRO series, PST-71, PST-110, PST-110HP
BRAND: Spid
TYPE: RAU, RAK, RAS, BIG-RAK, BIG-RAS (AZ part), Reed contact sensor
36
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A + B 6 + 7
CCW 2 MOTOR C + D 4 + 5
WIPER 3 SENSOR C 2
POT HI 4 SENSOR HI 3
POT LO 5 SENSOR LO 1
Rotator tab settings:
PARAMETER VALUE
SENSOR M-TURN POT 10 kΩ
MOTOR DC (reversible)
POWER 24 V (old 71D 48 V)
BRAKE NO
TOTAL ROTATION 500
LIMIT SWITCHES NO
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A + B 6 + 7
CCW 2 MOTOR C + D 4 + 5
SENSOR + 3 SENSOR HI 3
GND 4 SENSOR LO 1
OUT 5 SENSOR C 2
Rotator tab settings:
PARAMETER VALUE
SENSOR HALL
P/360º 2880
MOTOR DC (reversible)
POWER 24 V (48 V 110 HP)
BRAKE NO
TOTAL ROTATION 360
LIMIT SWITCHES NO
Rotator connection:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A + B 6 + 7
CCW 2 MOTOR C + D 4 + 5
REED B 3 SENSOR LO 1
REED A 4 SENSOR C + HI 2 + 3
Rotator tab settings:
PARAMETER VALUE
SENSOR REED
P/360º 360, BIG 720
MOTOR DC (reversible)
POWER 12 V
BRAKE NO
TOTAL ROTATION 720
LIMIT SWITCHES NO
