Using Functions
Functions are memories in which the current configuration of MK2R, including all headphone selections,
can be stored. Using these functions (memories), the operator can easily program and recall the MK2R
configuration for specific operating situations – for example: a small pile-up with multiplier hunting on the
second radio, a large pile-up, S&P on both radios, 40 meter split operation, etc.
MK2R has eight memories: F1 - F4 are accessed by pressing a single button and F5 – F8 are accessed by
holding + and pressing F1 – F4. These memories are retained in EEPROM when MK2R is turned off. The
contests of the memories can be saved to a file on the computer either individually or as a group. The
configuration files can be uploaded from the computer to MK2R and configuration files can be freely
exchanged between systems.
The current configuration can be stored to a memory by pressing any F-key for longer than one second and
the configuration saved in a function can be recalled with a short press of the F-key. Contents of the
memories can be protected by enabling “Function Lock” (a short press of the Power button).
These settings are stored with the function:
●
headphone selections for each state
●
AUTO RX focus (headphone) mode
●
AUTO TX focus mode
●
headphone MIX
●
MODE selections and status
●
RECORDING/DIGITAL channels selections
These setting are NOT saved:
●
TX focus
●
RX focus
●
STEREO signal
●
FRONT/REAR microphone selector
TIP: When creating functions, begin by recalling a configuration that is similar to the desired
function to minimize the required changes.
