Microlab FC362 - Technical Specifications; Amplifier and Speaker Specs; Interface and Power Details; Frequently Asked Questions (FAQ)

AMPLIFIER
SPEAKERS
INTERFACES
POWER
Output power: 54 Watt RMS
Power distribution: 15 Watt x 2 + 24 Watt
Harmonic distortion: < 0.3% 1W 1kHz
Frequency response: 35Hz - 20kHz
Signal/Noise ratio: > 75dB
Separation: > 45dB
Tweeter driver type: 2.5" x 2
Tweeter rated power: 15 Watt x 2, 4 ohm
Bass driver type: 6.5" - eAirbass
Bass rated power: 30 Watt, 8 ohm
Frequency range: 35Hz - 20kHz
Output: RCA sockets x 3
Input: 3.5mm Stereo, 2RCA sockets
Power supply: AC 220V - 240V ~ 50Hz, 200mA or
AC100V - 120V ~ 60Hz, 460mA
Specifications
65
Frequently Asked Questions (FAQ)
If the problem still exists, please contact the distributor or seek professional advice.
Check if the audio source is working well
Check if the audio and speaker cables well connected
Check if the volume at right level
Static sound heard when
volume knob is turned
What are the products
supported?
Where to place this speaker
Check if the source file is not corrupted, play a different
song and test.
heck if the satellite cable well connected, and ensure
source connection is correctly inserted
C
One or more satellite no sound
No Sound
Sound is distorted
Turn off the playback source first, then turn the speaker
volume knob several times. Playback again and monitor.
The static noise is due to dust, so simply turning the
volume will remove it easily.
It is magnetically shielded so can be placed near LCD TV
Monitor without any distortion
Any playback devices such as PC, notebook, CD/DVD
player, Media Players with 3.5mm stereo plug.
Solutions
Not to scale
Left
Sat
Right
Sat
Amplifier
Media player
Viewing screen
Subwoofer
2.1 subwoofer arrangement
Ideal listening position and placement
- The end -
All rights reserved
© 2010 Microlab Technology Co., Ltd
All specifications and information are subject to changes without further notice
80-FC361(10)-97-0001-01 2010-03-03
