6–19
MEASUREMENT MODE
:MEAS:RANGE <disc>
Select the required measurement range
condition for AC and RDC tests.
Parameters:
The following parameters are valid:
AUTO Auto-ranging.
HOLD Hold current range.
1 to 7 Range 1 to 7
Example: MEAS:RANGE 1
MEAS:RANGE AUTO
will select range 1 and auto-ranging
respectively.
Response:
None.
:MEAS:RANGE?
Returns the current measurement range.
Parameters:
None.
Response:
Returns the measurement range as an
integer according to this table:
0 Auto-ranging.
1-7 Current measurement range.
Example: 0
indicates that auto ranging is selected.
:MEAS:EQU-CCT <disc>
Select the equivalent circuit type for AC
tests.
Parameters:
The following parameters are valid:
SER Series equivalent circuit.
PAR Parallel equivalent circuit.
Example: :MEAS:EQU-CCT SER
will select the series equivalent circuit.
Response:
None.
:MEAS:EQU-CCT?
Returns the currently selected equivalent
circuit.
Parameters:
None.
Response:
Returns the equivalent circuit flag
according to this table:
0 Parallel.
1 Series.
Example: 0
indicates the parallel equivalent circuit
is selected.
