CONTENTS
1. Introduction 3
1.1 How to use the heat pump 3
1.2 Heat pump operation 3
1.3 Package checking 3
2. Safety measures 4
3. Product description and technical specification 5
3.1 Technical data 5
3.2 Swimming pool water parameters 5
3.3 Heat pump dimensions
5
3.4 Description of the basic parts 6
3.5 Safety and control systems
6
3.6 Block wiring diagram of the PCB board
7
4. Heat pump installation and connection 8
4.1 Positioning 8
4.2 Heat pump installation 9
4.3 Electric connection 11
4.3.1 Connection to the plug adapter 11
4.3.2 Fixed electric connection 11
5. Control unit 12
5.1 Functions of the control unit with LCD panel 12
5.2 Setting of the operating parameters 12
5.3 Turning on/off the operating / STAND-BY mode and setting
of the requested water temperature 13
5.4 Checking of the current values of some parameters 14
5.5 Timer setting 14
5.6 Control panel lock 14
6. Use and operation of the device 15
6.1 Operating instructions 15
6.2 Setting of the operating status by the by-pass 15
6.3 Water condensation 16
6.4 Possible problems caused by external factors
16
6.5 Comments on the heat pump operation 16
6.6 Simplified control diagram 17
7. Maintenance and checking of the device 18
7.1 Maintenance 18
7.2 Getting prepared for winter time 18
7.3 Warranty conditions, service and spare parts 19
7.4 Failure reports and their elimination 19
