I. OVEN SPECIFICATIONS – PS638G
Table 1-1 Dimensions
Single Oven Double Oven Triple Oven
Overall Height 42” (1066.8 mm) 51.25” (1301.8 mm) 63.50” (1612.9 mm)
Overall Depth 50” (1270 mm) 50” (1270 mm) 50” (1270 mm)
Overall Length 65.25” (1657 mm) 65.25” (1657 mm) 65.25” (1657 mm)
Conveyor Width – Belt width is 25” (635mm) 26.9” (683.3 mm) 26.9” (683.3 mm) 26.9” (683.3 mm)
Recommended Minimum Clearances
Rear of Oven to Wall 0” (0 mm)
Right Side of Oven to Wall 0” (0 mm)
Left Side of Oven to Wall 0” (0 mm)
Table 1-2: General Specifications PS638G
Weight 820 lbs. (372 kg) 1,640 lbs (744 kg) 2,460 lbs (1,488 kg)
Rated Heat Input (per oven cavity) 89,000BTU/hr (93.9MJ/h, 26.1 kW)
Maximum Operation Temperature 600°F (315 C)
Air Blowers 2 at 1,650 rpm
Warm-up Time 15-20 minutes to 500°F
Table 1-3: Electrical Specifications
Main Blower
Voltage
Control Circuit
Voltage
Phase Frequency
Current
Draw
Poles Wires
208/240 VAC, 3φ 24VDC 1 50-60 Hz 4.2/4.0 Amps 2 3 Wire – L1, L2/N & GRND
Table 1-4: Gas Orifice and Pressure Specifications
Gas Type
Main Orifice
Diameter
Inlet Pressure Manifold Pressure Bypass Orifice
Natural Gas
#39 = 0.0995”
(2.527mm) (72023)
7-9” W.C.
(1.7 – 2.2 kPa)
3.5” W.C. at manifold
(0.87 kPa)
#49 = 0.073”
(1.854mm) (59145)
Propane/ULPG
0.0689” (73785)
(1.75mm)
12-14” W.C.
(3.0-3.5 kPa)
6.0” W.C. at manifold
(1.49 kPa)
#55 = 0.052”
(1.321mm) (49948)
GAS ORIFICE AND PRESSURE SPECIFICATIONS (PER OVEN CAVITY) – CE OVENS
Gas
Type
Main Orifice
Diameter
AT,BG,CR,
CZ,DK,EE,
FI,GR,HR,
HU,IS,IE,
IT,LV,LT,
NO,PT,RO,S
K,SI,ES,
SE,CH,TR,G
B
NL
DE,
LU,
PL
BE,FR
FI,CR,GR,
IE,HR,LU,
NL,PL,SK,
SI,ES,CH,
TR,GB,CY,C
Z,DE,MT,SK
CY,CZ,
DE,
MT,SK
SW,CH,
AT,DK,
NO,FI,
NI,CR,
FR
BG,CY,CR,C
Z,DK,EE,FI,
GR,HR,
LV,LT,LU,
MT,NL,NO,S
K,SI,SE,
TR
PL /
AT,DE,
HU,SK,
CH
BE,CY,CZ,
EE,FR,
GR,IE,IT,
LT,LU,LV,P
T,RO,SK,E
S,CH,
GB,PL
Orifice
Manifold
Pressure
Rated
Heat
Input
I
2H
I
2L
I
2E
I
2E+
I
3P
I
3P
I
3B/P
I
3B/P
I
3B/P
I
3+
Natural
G20
#39
0.0995”
2.527 mm
20mbar --
20
mbar
20/25
mbar
-- -- -- -- -- --
3.5” w.c.
8.7mbar
25.9kW
Natural
G25
#39
0.0995”
2.527 mm
--
25
mbar
-- -- -- -- -- -- -- --
3.5” w.c.
8.7mbar
25.9kW
Butane
G30
0.0689
1.75mm
-- -- -- -- -- --
28-30/50
mbar
30 mbar
37/50
mbar
28-30
mbar
6.0” w.c.
14.9 mbar
29.2kW
Propane
G31
0.0689
1.75mm
-- -- -- -- 37 mbar 50 mbar -- 30 mbar
37/50
mbar
37 mbar
6.0” w.c.
14.9 mbar
25.8kW
NOTE
Wiring Diagrams are contained in Section 5 of this Manual and are also located inside the oven
control compartment. Additional electrical information is provided on the oven’s serial plate.
THIS MANUAL MUST BE KEPT FOR FUTURE REFERENCE
To Next Page
