Midea Aqua Tempo Super MC-SS80/RN1L

Aqua Tempo Super Series air cooled scroll chiller unit (50Hz) MCAC-ATSM-201606
141
16.4.4 External dimension
There are three installation methods as the following figure. Do not install the unit in any other orientation
29 1
31 9
251
268.8
61
15
22
16.4.5 Connection Method
Connection Method 1
Air-cooled scroll chiller:Max. 16 units
LONWORKS
NET WORK
LSQ-LONWORKS
BMS SYSTEM
RS485(P Q E)
