- 24 -
• Machine and medical facility.
• A place there is no combustive gases and volatile matter.
• A place of special environmental conditions.
Installation in the following places:
• A place where is no obstacle near the inlet and outlet area.
• A place which can bear the indoor unit.
• A place which is convenient to maintenance.
• A place which provides the space around the indoor unit as required right in the diagram.
• There is strong electromagnetic wave existing.
• A place which is far from heat, steam and inflammable gas.
12.4.2 Drilling A Hole and Mounting Installation Board
Installation Board and Its Direction (unit: mm)
250\300\400 type 500\600 type
1. Fix the installation board
• Install the installation board horizontally on structural parts on the wall with the spaces provided around the plate.
• In case of brick, concrete or similar type walls, make 5mm dia. holes on the wall. Insert clip anchors for appropriate
mounting screws.
• Fix the installation board on the wall.
Right installation
False installation
2. Drilling a hole
• Determine the pipe hole position using the installation board, and drill the pipe hole (N95mm) so it slants slightly
downward.
460
25
290
915
mounting board of indoor unit
the shape of indoor unit
730
316
1070
36
m
o
u
n
t
i
n
g
b
o
a
r
d
o
f
i
n
d
o
o
r
u
n
i
t
the shape of indoor unit
