Midea C Series User Manual

AC Fan Coil Unit Two-pipe Wall-
mounted Series
- 68 -
Cooling capacity
MKG-400-C/ MKG-400-D
EWT ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21 23 25 27 29
TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD
°C °C °C kW kW m
3
/h kPa kW kW m
3
/h kPa kW kW m
3
/h kPa kW kW m
3
/h kPa kW kW m
3
/h kPa
5
4
15 2.17 1.81 0.46 15.29 2.19 2.11 0.47 15.60 2.42 2.41 0.52 18.57 2.71 2.71 0.58 22.40 3.00 3.00 0.64 26.63
17 3.06 1.82 0.66 27.49 3.04 2.12 0.65 27.22 3.02 2.42 0.65 26.94 3.00 2.71 0.64 26.60 3.06 3.01 0.66 27.48
19 - - - - 3.99 2.13 0.86 43.44 3.97 2.43 0.85 43.02 3.94 2.72 0.85 42.63 3.92 3.01 0.84 42.25
5
15 1.81 1.65 0.31 6.60 1.96 1.95 0.34 8.11 2.25 2.25 0.39 11.03 2.55 2.55 0.44 13.74 2.85 2.85 0.49 16.70
17 2.70 1.66 0.46 15.24 2.68 1.96 0.46 15.08 2.66 2.26 0.46 14.86 2.68 2.56 0.46 15.09 2.85 2.85 0.49 16.77
19 - - - - 3.63 1.97 0.62 25.06 3.61 2.27 0.62 24.82 3.59 2.56 0.62 24.57 3.57 2.86 0.61 24.33
7
4
15 1.55 1.51 0.33 8.16 1.82 1.82 0.39 11.25 2.12 2.12 0.46 14.68 2.41 2.41 0.52 18.15 2.71 2.71 0.58 22.09
17 2.36 1.52 0.51 17.52 2.34 1.82 0.50 17.27 2.33 2.12 0.50 17.12 2.44 2.42 0.53 18.53 2.71 2.71 0.58 22.15
19 - - - - 3.31 1.83 0.72 31.44 3.29 2.13 0.71 31.12 3.27 2.43 0.71 30.80 3.25 2.72 0.70 30.43
5
15 1.38 1.38 0.24 3.32 1.66 1.66 0.29 5.50 1.95 1.95 0.34 8.31 2.25 2.25 0.39 11.01 2.55 2.55 0.44 13.59
17 1.96 1.35 0.34 8.35 1.94 1.65 0.33 8.19 2.02 1.96 0.35 8.98 2.26 2.26 0.39 11.04 2.56 2.56 0.44 13.62
19 - - - - 2.92 1.67 0.50 17.13 2.90 1.97 0.50 16.95 2.94 2.35 0.53 57.16 2.86 2.56 0.49 16.57
9
4
15 1.22 1.22 0.26 4.46 1.51 1.51 0.33 7.83 1.82 1.82 0.39 11.05 2.12 2.12 0.46 14.31 2.42 2.42 0.52 17.97
17 1.60 1.21 0.34 8.79 1.62 1.52 0.35 9.07 1.82 1.82 0.39 11.10 2.12 2.12 0.46 14.35 2.42 2.42 0.52 18.02
19 - - - - 2.57 1.53 0.55 19.92 2.55 1.83 0.55 19.68 2.52 2.12 0.54 19.38 2.55 2.42 0.55 19.76
5
15 1.08 1.08 0.19 1.99 1.37 1.37 0.24 3.42 1.66 1.66 0.29 5.73 1.96 1.96 0.34 8.44 2.26 2.26 0.39 10.88
17 1.25 1.07 0.22 2.68 1.40 1.37 0.24 3.63 1.66 1.66 0.29 5.75 1.96 1.96 0.34 8.46 2.26 2.26 0.39 10.91
19 - - - - 2.14 1.36 0.37 9.89 2.11 1.66 0.36 9.71 2.14 1.96 0.37 9.91 2.30 2.27 0.40 11.18
11
4
15 0.93 0.93 0.20 2.24 1.22 1.22 0.26 4.60 1.52 1.52 0.32 7.85 1.82 1.82 0.39 10.80 2.12 2.12 0.45 13.98
17 0.97 0.93 0.21 2.48 1.22 1.22 0.26 4.62 1.52 1.52 0.33 7.87 1.82 1.82 0.39 10.83 2.12 2.12 0.45 14.01
19 - - - - 1.75 1.22 0.37 10.06 1.74 1.52 0.37 10.02 1.87 1.83 0.40 11.29 2.12 2.12 0.46 14.05
5
15 0.79 0.79 0.14 1.33 1.09 1.09 0.19 1.97 1.37 1.37 0.24 3.57 1.66 1.66 0.29 5.94 1.96 1.96 0.34 8.44
17 0.80 0.79 0.14 1.34 1.09 1.09 0.19 1.98 1.38 1.38 0.24 3.59 1.67 1.67 0.29 5.96 1.97 1.97 0.34 8.46
19 - - - - 1.33 1.07 0.23 3.29 1.44 1.37 0.25 4.11 1.67 1.67 0.29 5.99 1.97 1.97 0.34 8.49
13
4
15 0.63 0.63 0.14 1.29 0.93 0.93 0.20 2.33 1.22 1.22 0.26 4.86 1.52 1.52 0.33 7.82 1.82 1.82 0.39 10.64
17 0.64 0.64 0.14 1.29 0.93 0.93 0.20 2.34 1.22 1.22 0.26 4.88 1.52 1.52 0.33 7.84 1.82 1.82 0.39 10.66
19 - - - - 1.00 0.93 0.22 2.85 1.22 1.22 0.26 4.89 1.52 1.52 0.33 7.86 1.83 1.83 0.39 10.69
5
15 0.49 0.49 0.08 0.78 0.79 0.79 0.14 1.26 1.08 1.08 0.19 1.96 1.37 1.37 0.24 3.65 1.66 1.66 0.29 6.01
17 0.49 0.49 0.08 0.78 0.79 0.79 0.14 1.26 1.09 1.09 0.19 1.97 1.37 1.37 0.24 3.67 1.67 1.67 0.29 6.03
19 - - - - 0.81 0.79 0.14 1.28 1.09 1.09 0.19 1.97 1.37 1.37 0.24 3.69 1.67 1.67 0.29 6.05
15
4
15 0.33 0.33 0.07 0.64 0.63 0.63 0.14 1.22 0.93 0.93 0.20 2.37 1.22 1.22 0.26 4.93 1.52 1.52 0.33 7.74
17 0.33 0.33 0.07 0.64 0.64 0.64 0.14 1.22 0.93 0.93 0.20 2.38 1.22 1.22 0.26 4.95 1.52 1.52 0.33 7.76
19 - - - - 0.64 0.64 0.14 1.22 0.93 0.93 0.20 2.39 1.22 1.22 0.26 4.97 1.53 1.53 0.33 7.78
5
15 0.18 0.18 0.03 0.27 0.49 0.49 0.08 0.75 0.79 0.79 0.14 1.21 1.09 1.09 0.19 2.04 1.37 1.37 0.24 3.85
17 0.18 0.18 0.03 0.27 0.49 0.49 0.08 0.75 0.79 0.79 0.14 1.21 1.09 1.09 0.19 2.05 1.37 1.37 0.24 3.87
19 - - - - 0.49 0.49 0.09 0.75 0.80 0.80 0.14 1.21 1.09 1.09 0.19 2.06 1.38 1.38 0.24 3.88
Abbreviations:
EWT: Enter Water Temp. (℃) Δt: Temperature Difference. (℃) DB: Dry Bulb Temp. (℃)
WF: Water Flow. (m
3
/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity. (kW) SC: Sensible Cooling Capacity. (kW) WPD: Water Pressure Drop. (kPa)
