AC Fan Coil Unit Two-pipe Wall-mounted Series
- 65 -
Heating Capacity
MKG-600-B
EWT ΔT
Indoor temperature (W.B.)
16 18 20 22
TH WF WPD TH WF WPD TH WF WPD TH WF WPD
°C °C kW m
3
/h
kPa kW m
3
/h
kPa kW m
3
/h kPa kW m
3
/h kPa
40
8 5.28 0.57 14.79 4.65 0.50 11.96 4.01
0.43 9.39 3.38
0.36 7.08
10 5.33 0.46 8.74 4.61 0.40 6.86 3.88 0.33 5.17 3.16 0.27 3.68
12 - - - - - - - - - - - -
14 - - - - - - - - - - - -
16 - - - - - - - - - - - -
45
8 6.51 0.70 23.27 5.90 0.63 19.80 5.30
0.57 16.59 4.70
0.51 13.61
10 6.24 0.54 13.61 5.61 0.48 11.40 4.98 0.43 9.37 4.35 0.37 7.50
12 5.99 0.43 8.60 5.32 0.38 7.07 4.65
0.33 5.66 3.98
0.29 4.38
14 5.66 0.35 5.57 4.95 0.30 4.46 4.24
0.26 3.45 3.53
0.22 2.55
16 4.99 0.27 3.05 4.27 0.23 2.36 3.55 0.19 1.74 2.83 0.15 1.20
50
8 7.79 0.84 33.85 7.20 0.77 29.70 6.61
0.71 25.81 6.03
0.65 22.17
10 7.49 0.64 19.96 6.89 0.59 17.36 6.28 0.54 14.91 5.68 0.49 12.63
12 7.26 0.52 12.94 6.63 0.47 11.12 5.99 0.43 9.42 5.37 0.38 7.85
14 6.98 0.43 8.71 6.31 0.39 7.38 5.65
0.35 6.15 4.99
0.31 5.01
16 6.68 0.36 6.08 5.98 0.32 5.06 5.28 0.28 4.12 4.58 0.25 3.27
55
8 9.04 0.97 46.00 8.46 0.91 41.23 7.88
0.85 36.69 7.31
0.79 32.42
10 8.78 0.76 27.70 8.18 0.70 24.66 7.59
0.65 21.79 7.01
0.60 19.09
12 8.53 0.61 17.99 7.92 0.57 15.90 7.31 0.52 13.93 6.70 0.48 12.07
14 8.24 0.51 12.31 7.61 0.47 10.78 6.98
0.43 9.35 6.35
0.39 8.00
16 7.96 0.43 8.82 7.30 0.39 7.64 6.65
0.36 6.54 5.99
0.32 5.52
60
8 10.31 1.11 60.33 9.74 1.05 54.85 9.17 0.99 49.65 8.60 0.92 44.70
10 10.10 0.87 36.94 9.51 0.82 33.45 8.93
0.77 30.13 8.35
0.72 26.96
12 9.87 0.71 24.28 9.27 0.66 21.87 8.66 0.62 19.58 8.07 0.58 17.41
14 9.61 0.59 16.88 8.98 0.55 15.11 8.37
0.51 13.43 7.75
0.48 11.85
16 9.33 0.50 12.22 8.69 0.47 10.86 8.05
0.43 9.57 7.42
0.40 8.37
Abbreviations:
Δt: Temperature Difference. (℃)
TH: Total Heating Capacity. (kW) WF: Water Flow. (m
3
/h)
WPD: Water Pressure Drop. (kPa)
