Indoor Unit
Installation
●
Fasten and x the wire body with a tie.
Page 23
Fasten and x the wire body with a tie
●
Install the circuit breaker cover by xing the
two screws.
Two screws
Model B: with terminal
●
Remove the four screws to open the indoor
control box and terminal box.
●
Remove the pre-cutting cover on the terminal
box. Remove the two screws, then take out the clip.
Four screws
Pre-cutting cover
Two screws
To Next Page
