Panel Installation
●
Pull the panel grille out of the panel, x the
cassette panel to the one-way cassett by two
plastic buckles.
●
Grab air grille with your ngers and pull it out
slowly in the direction of the arrow.
NOTICENOTICE
The corresponding colors or corresponding
pins are connected each other.
when connection is completed, please clip
the wires to the buckle.
●
Manually rotate the air deector, x the panel
to the cassette by using 3×M4*22 screws and a
ST3.9*16 screw.
Before xing this screw, you need to open the screw cover;
and after xing screw, please close the cover.
Panel Installation
Step1 Prepare and install ceiling
●
Connect the display board to the main control
board, up to four wires are required to connect.
●
Open the two covers on both sides of the panel ,
x the panel to the cassette by using 3× M4*22
screws.
M4*22 screw
(white 10-core)
(white 5-core)
(red 5-core)
( 4 core)
●
Drill 430 mm x 1300 mm( 16.93’’x51.18’’ )
hole into the ceiling based on the layout of
the installation board.
The centre of the ceiling opening should
match the centre of the body of the indoor
unit.
NOTICE
Eight M4*22 screws are
supplied, two of which are
spare. Two ST3.9*16 screws
are supplied, one of which is spare.
NOTICE
●
then install the ceiling.
Step 2 Panel Installation
●
Once the ceiling is cut, remove the installation
board.
In order to keep the ceiling level and prevent
vibrations, reinforce the strength of the ceiling
when necessary.
●
The air grille received by the customer is not
tightened by the wire rope,but is specially
designed to be loose for easy installation.
NOTICE
Model A
Grab at these locations
M4*22 screw
ST3.9*16 screw
Page 43
To Next Page
