Midea CBU-06HRFN1-MV0W - Page 41

Refrigerant
piping
Connection
Φ 12.7( 1/2in)
R410A:
(orice tube in the indoor unit):

Page 41
Refrigerant
(Total pipe length-
standara pipe length)
×30g(0.32oz)/m(ft)
(Total pipe length-
standara pipe length)
×65g(0.69oz)/m(ft)
(Total pipe length-
standara pipe length)
×115g(1.23oz)/m(ft)
(Total pipe length-
standara pipe length)
×15g(0.16oz)/m(ft)
(Total pipe length-
standara pipe length)
×30g(0.32oz)/m(ft)
(Total pipe length-
standara pipe length)
×65g(0.69oz)/m(ft)
R410A:
(orice tube in the outdoor unit):
Φ 9.52( 3/8in)
Φ 6.35( 1/4in)
Liquid Side Diameter
