8
XVIIII. Spray Arm Assembly
If the spray arm assembly is blocked, unscrew the nut beneath the spray arm and remove
the spray arm to wash out the obstacles. Note: the spray arm nut is turned to the left. When
removing the obstacles, do not dig or pry the spray arm and nozzle. Otherwise, the washing
effect and the service life of the spray arm may be compromised.
XX. Explosion Diagram and Schedule
XXI. Circuit Diagram
XXII. Consumables List
container of the dishwasher. It slows the growth of sediment in the inner container and
improves the efficiency of the dishwasher powder.
The water softener may have such troubles as
a. After five rounds of salted washing, the out-of-salt pilot remains on.
Possible causes and solutions:
(1) Incorrect float position in the salt spoon. Replace the salt spoon.
(2) Switch subassembly failure. Replace the switch subassembly.
(3) Twisted hose. Straighten up the hose.
(4) Incorrect wire connection. Check the wires.
b. After 50 rounds of salted washing, the out-of-salt pilot remains off.
Possible causes and solutions:
(1)Electromagnetic valve failure in the salt spoon. Replace the electromagnetic valve.
(2) One-way valve failure in the salt spoon. Replace the one-way valve.
(3) Incorrect float position in the salt spoon. Replace the salt spoon.
(4) Pilot failure. Replace pilot.
(5) Switch subassembly failure. Replace the switch subassembly.
(6) Incorrect wire connection. Check the wires.
(7) Twisted hose. Straighten up the hose.
c. During the feeding of the water, large amount of water directly flows from the water tank
to the inner container.
(1) Incorrect water distribution in the water tank. Replace the water tank.
(2) Twisted inlet hose. Straighten up the hose.
XIX. Water Softener
