6.Internal view and dimension
6.1Main parts and their names
1
2
3
4
5
6
11
10
9
8
7
(The picture is only for reference, and specific appearance and configuration are subject to the real
product)
Freezer chamber
Refrigerator chamber
1. Toolbar
2. Steel column strip
3. Zip-top can steel bar
4. Zip-top can steel bar
5. Steel column strip
6. Steel column strip
7. Fruits and vegetables box
8. Glass shelf assembly
9. Glass shelf assembly
10. Ice box
11. Temperature-control box assembly
