12. Figures and details of repair parts(Documentsareprovidedseparately)
12.1Figures
12.2List of parts and components
13Appendix:
13.1Electrical Schematic Diagram(None)
（Model：***）
13.2Refrigerator maintenance tooling and equipment and material
Tooling
No.
Name
Main Usage
1
Phillips screwdriver
screw assemble and disassemble
2
slotted screwdriver/scraper
screw and rivet assemble and
disassemble
3
Socket spanner 5/16″
hinge and compressor screw
assemble and disassemble
4
Sucker
display panel and air duct
cover disassemble
