Midea CE-BCD87CM-SQ - A Ir Duct Components in Freezing Chamber and Fan Motor; Evaporator and Temperature Sensing System; Compressor Case

Service Manual, 2017-02
19 / 31
8.5Air duct components in freezing chamber and fan motor
Disassembly and installation of Air duct
None
Fan motor of air duct
None
8.6Evaporator and temperature sensing system
Evaporator in freezing chamber
not replace
Components on the evaporator
Defrost thermostat
None
Fuse
None
Defrost sensor
None
Defrost heater
None
Evaporator in refrigerating chamber
None
Components on the evaporator
None
Sensor
Sensor in freezing chamber
None
Sensor in refrigerating chamber
None
Sensor in Variable temperature chamber
None
ambient temperature senser
None
Thermostat
Remove the lamp cover and insert pin, remove the screw
under insert pin, outward pulling the thermostat-control
box at horizontal
pull out the knod,remove the socket the terminal,replace
the thermostat
8.6Compressor case
Piping system in the compressor case
