DISASSEMBLY INSTRUCTIONS SIZES 9−12K (208−230V) (CONT)
3) Pull out connectors of
the condenser coil
temp. sensor
(T3),outdoor ambient
temp. sensor (T4) and
discharge temp.
sensor (T5).
4) Disconnect the
electronic expansion
valve wire.
5) Remove the
grounding screw.
6) Remove the wires (1,
2, 3). Then remove
the electronic control
box.
ƻ
4
ƻ
5
ƻ
6
