Midea DLCERAH12AAJ

32808001101 67
Specifications subject to change without notice.
DISASSEMBLY INSTRUCTIONS SIZES 24K (208−230V) (CONT)
3
parts
Electrical
1)
How to remove the
electrical parts.
2) Pull out the two blue
3)
After completing the
work in sections 1 and
2, remove the
compressor connector.
wires connected with
the four way valve.
1
2
3
Pull out connectors of
the condenser coil
temp. sensor (T3),
outdoor ambient temp.
sensor (T4) and
discharge temp.
sensor (T5).
