9 UNPACKING WAYS OF MAIN PARTS
11. Undo the absorber pin
from the cabinet
Use pliers to pinch the
absorber pin’s
protuberance, and knock
the absorber pin out from
back lightly; in the same
way, remove the other one
12.Undo the drum tub
assembly
Undo the upper and façade
counterweight
I.Remove 3 screws fit
on the upper
counterweight and then
pull out it.
II.Remove 6 screws pull
out the facade
counterweight.
Undo the panel support
Remove two screws
fixing the panel support,
and then remove it.
