Disassembly of freezing upper drawer:
1) Open the freezing door to the place of maximum
stroke, lift the tail of freezing upper drawer, hold on the
slide rail to prevent its movement;
2) Push the drawer forward to make the drawer separate
from rhe slide rail supporting claw, rotate over the rear,
and take out the drawer.
Disassembly of freezing lower drawer:
1) Open the freezing door to the place of maximum
stroke, hold the left and right side of the freezer lower
drawer, and uplift the tail;
2) Pull the whole drawer towards the box outside till the
slide rail supporting buckle is separated from the drawer,
rotate over the rear, and take out the drawer.
1) Freezing drawer shall be taken out first for the
disassembly of freezer slide rail;
2) Remove the screw in the red circle as shown in the
right diagram, and take out the slide rail.
3）。
3) Disassembly of guide rail connecting rod.
Disassemble the insertion terminal on left side of the
guide rail connecting rod, and then move the guide rail
connecting rod in the direction of arrow 2, and take it
down.
