Midea HC-808WE - Page 45

Service Manual_2020-V1.0
45
4-1）Remove the screws(for some models)
-Two screws outside
-One screw inside
4-2）Remove the metal clamp(for some models)
-Disassembly the metal clamp that is fix the electric
appliance shield
5）Remove the clipping strip
Slowly pull it out
6）Remove the protective cover
-Pry the protective cover slowly from the upper part,
-Pull it out and remove it.
