Service Manual_2020-V1.0
10
3.4 Leveling of the refrigerator
Leveling of the refrigerator
If the refrigerator cannot be placed steadily, adjust the
footing to level it. Turn the feet clockwise to raise the
refrigerator; turn the feet counterclockwise to lower the
refrigerator.
3.5 Left or right open door reversal
1) Power off and remove all food from the fridge.
2)Dismantle the upper hinge cover, screws and upper hinge
from the right top, and remove the cover plate from the left
top.
3)Take off the freezer door.
4)Unscrew the three screws holding the center hinge,
remove the hinge, then lift the refrigerator door up and away
from bottom hinge.
To Next Page
