Service Manual_2020-V1.0
35
8. Temperature sensing system
8.1 Position of sensors
8.2 Replacement of sensors
Sensor in refrigerating chamber
The refrigerating air duct components should be
dismantled before removing this sensor.
1) Strip the tape that secures the wiring harness.
2) Then remove the sensor.
Ambient temperature sensor
The sensor is located in the hinge cover of the
refrigerator top.
Have3 sensors
②Sensor in refrigerating chamber
④Ambient temperature sensor
⑦Defrost sensor in freezing chamber
