Midea HD-663FWEN - Refrigeration System Principles

Service Manual_2020-V1.0
21
6. Refrigeration system
6.1 Refrigeration system working principle
❶Compressor→❷ Anti-condensation tube→❸ Condenser→❹ Dry filter→❺ Capillary tube→❻
Evaporator→❼ Suction tube→❶Compressor
6.2 Cooling pipeline and drain pipe inside the cabinet
