Midea HD-663FWEN

Service Manual_2020-V1.0
25
Shelves
Lift up the division plate with a proper force and pull it out
towards yourself;
Freezer Drawer(None)
None
None
7.3 Light system
Light
Light of the refrigerating
1）Remove the lamp cover
2）Remove the light.
3) The reverse process can complete installation.
Light of the freezing
None
Light switch
There is a light switch on the side wall of the refrigerating
chamber.1）Loosen the hook with small normal
screwdriver and pull out the switch until the wire
connector reveals.
7.4 Air duct components refrigerating chamber and fan motor
Air duct components in freezing chamber
