Midea HD-663FWEN

Service Manual_2020-V1.0
30
4-2）Remove the metal clamp(for some models)
-Disassembly the metal clamp that is fix the electric
appliance shield
5）Remove the clipping strip
Slowly pull it out
6）Remove the protective cover
-Pry the protective cover slowly from the upper part,
-Pull it out and remove it.
7）Remove the starter and protector
Unplug the starter and protector (you can use a
screwdriver to pry it slowly)
