09
6.1 Dimensions
6 INSTALLATION PRECAUTIONS
Model A B C D E F G H I
4/6kW
8/10kW
974
1075
333
363
378
411
590
625
164
184
119
126
179
179
857
965
75
117
4/6 kW (unit: mm)
8/10 kW (unit: mm)
Check the strength and level of the installation ground so that the unit may not cause any vibrations or noise during the
operation.
In accordance with the foundation drawing in the figure, fix the unit securely by means of foundation bolts. (Prepare four sets
each of Φ10 Expansion bolts, nuts and washers which are readily available in the market.)
Screw in the foundation bolts until their length is 20 mm from the foundation surface.
6.2 Installation requirements
(unit: mm)
Concrete
basement
h100mm
Rubber
shocking
proof mat
100
80
Φ10 Expansion
bolt
Solid
ground
or roofing
A
B
C
E D
H
H
F G
F G
I
I
A
B
C
E D
Fig: 6-3
Fig: 6-1
Fig: 6-2
Fig: 6-4
