Door 1
To access to the compressor and
electrical parts.
Door 1
To access to the compressor and
electrical parts
4/6kW
8/10kW
Push the grill to the left until it stops, then pull its right edge, so you can removed the grill. You can also reverse the procedure.
Be careful to avoid hand injury.
WARNING
Switch off all power — i.e. unit power supply and backup heater and domestic hot water tank power supply (if applicable)
— before removing doors 1.
Parts inside the unit may be hot.
9.2 Electronic control box
PCB A
PCB B
4/6kW
1 1
18
