Midea MFJ-48ARN1-RB6 User Manual

Exploded view & spare-part
24
Specification
Model
ModelModel
Model
MFJ-24ARN1-QB8 MFJ-48ARN1-RB6
Factory Code
Factory CodeFactory Code
Factory Code
2T004330T031 2T004370T020
Electrical Data
Electrical DataElectrical Data
Electrical Data
Power supply Ph-V-Hz
1φ,220-240V,50HZ 3φ,380-420V,50HZ
Capacity
Cooling/Heating
Btu/h
24000/27000+7200 46000/49000+12000
Power consumption
Cooling/Heating
W
2500/2450+2100 5200/5100+3500
Rated current Coo
ling/Heating
A
12/11.5+9.6 8.6/8.5+5.6
EER
Cooling/Heating
Btu/w.h
9.5/10.9 8.9/10.2
System data
System dataSystem data
System data
Refrigerant type g
R410A/2000 R410A/4500
Design pressure MPa
4.2 4.2
Air flow m3/h
1100 1750
Noise level
Indoor dB(A)
48 50
Outdoor dB(A)
60 62
Dimension&Weight
Dimension&WeightDimension&Weight
Dimension&Weight
Indoor
Dimension (W*H*D)
mm
500x1700x290 540x1825x410
Packing (W*H*D) mm
615x1805x415 655x1935x555
Net/Gross weight
Kg
41.5/58.5 58/75
Outdoor
Dimension (W*H*D)
mm
840x695x335 940x1245x360
Packing (W*H*D) mm
965x755x395 1018x1380x435
Net/Gross weight
Kg
60/63 104/115
Refrigerant piping
Refrigerant pipingRefrigerant piping
Refrigerant piping
Liquid side/ Gas side mm
Ф9.53/Ф16 Ф12.7/Ф19
Max. refrigerant pipe length m
20 30
Max. difference in level m
10 15
Applicable ambient
Applicable ambientApplicable ambient
Applicable ambient
Ambient temp
℃ -7-45 -7-45
Application area m2
40-56 80-112
Compressor
CompressorCompressor
Compressor
Compressor
Model
PA290X3CS-4MU1 C-SBN373H8D
Type
Rotary Scroll
Brand
GMCC Sanyo
Capacity Btu/h
24490 48109
Input W
2430 4750
Rated current(RLA) A
11.4 8.22
Locked rotor Amp(LRA)
A
61 66
Thermal protector
UP14SE5145 internal
Capacitor uF
50 No
Refrigerant oil ml
950 1700
Fan Motor
Fan MotorFan Motor
Fan Motor
Indoor Model
YDK75-8 YDK120-8T
