Midea MGBT-F180W/DN1 - Mgbt-F120 W;Dn1; Mgbt-F180 W;Dn1

MCAC-ATSM-2014-09 R410a tropical air-cooled scroll chiller unit 60Hz
Capacity tables 31
3.3 MGBT-F120W/DN1
Each module has four compressors with two separate units, one shell and tube evaporate for four systems.
Shell-tube
evaporator
Condenser
Water flow direction
Compressor B
low pressure cylinder B
4-Way valve A
Fan A
EXV
Capillary
EXV
Capillary
Fan B
4-Way valve B
Compressor A
low pressure cylinder A
Unit 2
Unit 1
3.4 MGBT-F180W/DN1
Each module has six compressors with three separate units, one shell and tube evaporate for six systems.
Shell-tube evaporator
Condenser
Water flow direction
Compressor B
low pressure cylinder B
4-Way valve A
Fan A
EXV
Capillary
EXV
Unit 2
Unit 3
Capillary
Fan B
4-Way valve B
Compressor A
low pressure cylinder A
Unit 1
