R410a tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
136 Installation
3.2 MGBT-F60W/DN1
Installation of single-module water system pipeline
Total water outlet
temperature sensor
Water outlet Water inlet
Electric control box
Installation of multi-module water system pipeline
1) Installation mode I (recommended installation mode)
No.n module
No.(n-1) address
No.1 moduleNo.(n-1) module
No.(n-2) address No.0 address
Water flow switch
Pump
(less than 6 modules)
n :the module quantity, max 6
