Midea MGBT-F25W/DN1

R410a tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
128 Installation
Input of airflow
Input of airflow
A
B
D
C
Input of airflowInput of airflow
E
MGBT- F180W/DN1
The recommend space parameter
Module
Installation space (mm)
A
B
C
D
E
MGBT-F25W/DN1
≥1500
≥2000
≥1500
≥2000
≥8000
MGBT-F30W/DN1
MGBT- D25W/DN1
MGBT- D30W/DN1
MGBT-F60W/DN1
MGBT-F120W/DN1
MGBT-F180W/DN1
≥2000
≥2000
