Midea MGBT-F25W/DN1 - Specification: MGBT-F60 W;DN1, MGBT-F120 W;DN1

MCAC-ATSM-2014-09 R410a tropical air-cooled scroll chiller unit 60Hz
Capacity tables 13
1.8 Specification: MGBT-F60W/DN1, MGBT-F120W/DN1
Model
MGBT-F60W/DN1
MGBT-F120W/DN1
Cooling Capacity (*1)
kW
60
120
Btu/h
204,700
409,400
Cooling Capacity (*2)
kW
51.6
103.2
Btu/h
176,100
352,100
Heating Capacity
kW
65
130
Power supply
V/Ph/Hz
220/3/60
220/3/60
Power supply
Manual switch
A
175
350
Fuse
A
150
300
Compressor
Type
Scroll (fixed speed)
Scroll (fixed speed)
Brand
Danfoss
Danfoss
Model
SH105A3ALC
SH105A3ALC
Quantity
Pieces
2
4
Power input
Cooling (*1)
kW
19.5
39
Cooling rated current (*1)
A
63
126
Cooling (*2)
kW
23.4
46.8
Cooling rated current (*2)
A
75.6
151.2
Heating
kW
20
40
Heating rated current
A
65.5
130
Max. Input consumption
kW
26.2
54.5
Max. Current
A
87.2
164.7
Refrigerant
Type
R410A
R410A
Refrigerant control
EXV+ capillary throttle
Weight
kg
6.5×2
6.5×4
Condenser (Air
side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
2
4
Air flow volume
×10
3
m
3
/h
24
48
Fan motor model
YS650-8B
YS650-8B
Fan motor rated current
A
3.7×2
3.7×4
Fan motor input
kW
0.65×2
0.65×4
Evaporator
(Water side)
Water side heat-exchanger type
Shell-tube
Shell-tube
Water pressure drop
kPa
12
25
Water inlet/outlet pipeline
inside normal diameter
mm
DN100
DN65
inch
4”
2-1/2”
Water flow volume
m
3
/h
10.3
20.6
Max. Pressure
MPa
1
1
Volume
L
42
64
Water pipe connection type
Flexible joint
Flexible joint
Dimension
Net(W×H×D)
mm
2000×1880×900
2000×2090×1685
inch
78.7×74×35.4
78.7×82.3×66.3
Packing size(W×H×D)
mm
2090×2055×985
2080×2240×1755
inch
82.3×80.9×38.8
81.9×88.2×69
Weight
Net weight
kg
580
1180
lbs.
1278.7
2601.5
Gross weight
kg
650
1230
lbs.
1433
2177.7
