Midea MGBT-F25W/DN1 User Manual

MCAC-ATSM-2014-09 R410a tropical air-cooled scroll chiller unit 60Hz
Capacity tables 11
1.7 Specification: MGBT-F30W/DN1, MGBT-D30W/DN1
Model
MGBT-F30W/DN1
MGBT-D30W/DN1
Cooling Capacity (*1)
kW
30
Btu/h
102,300
Cooling Capacity (*2)
kW
25.8
Btu/h
88,030
Heating Capacity
kW
32
Power supply
V/Ph/Hz
220/3/60
Power supply
Manual switch
A
70
Fuse
A
50
Compressor
Type
Scroll (fixed speed)
Digital Scroll + Fixed speed
Brand
Sanyo
Copeland / Sanyo
Model
C-SBP160H36A
ZPD51K5E-TF5-532/
C-SBP160H36A
Quantity
Pieces
2
1+1
Power input
Cooling (*1)
kW
10.0
Cooling rated current (*1)
A
28.3
Cooling (*2)
kW
12
Cooling rated current (*2)
A
33.96
Heating
kW
9.8
Heating rated current
A
27.7
Max. Input consumption
kW
14.7
13.7
Max. Current
A
43.7
39.9
Refrigerant
Type
R410A
Refrigerant control
EXV
Weight
kg
3.0×2
Condenser (Air
side)
Air side heat-exchanger type
Fin-coil
Quantity of fan motor
Pieces
1
Air flow volume
×10
3
m
3
/h
12
Fan motor model
YDK500-8B
Fan motor rated current
A
4
Fan motor input
kW
0.85
Evaporator
(Water side)
Water side heat-exchanger type
Double-pipe
Water pressure drop
kPa
60
Water inlet/outlet pipeline
inside normal diameter
mm
DN40
inch
1-1/2”
Water flow volume
m
3
/h
5.2
Max. Pressure
MPa
1
Volume
L
10
Water pipe connection type
Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
Packing(W×H×D)
mm
1590×2065×995
inch
62.6×81.3×39.2
Weight
Net weight
kg
380
lbs.
837.8
Gross weight
kg
400
lbs.
881.8
