Midea MGBT-F25W/DN1

R410a tropical air-cooled scroll chiller unit 60Hz MCAC-ATSM-2014-09
No.
Part Name
Qty
No.
Part Name
Qty
1
The top beam
2
35.3
Meter connector
2
2
The condenser seal fittings. II
2
36
Fixed plate
4
3
Iron nets fixed plate. II
2
37
Pipe fixing clamp
6
4
Protect net around
4
38
Welding parts water tray
2
5
pole
4
39
Condenser seal plate ass'y
2
6
Trough fixation plate
4
40
Condenser parts of unit A
2
7
Left right panel by. II
1
40.1
Condenser ass'y of unit A
1
8
Iron nets fixed board I
2
40.2
Flute-shaped tube ass'y of unit A
1
9
Protect network and
4
40.3
Distributor ass'y of unit A
condenser
1
10
In the frame beams
2
41
Condenser fixed plate ass'y of unit
A
2
11
Cover
1
42
Motor bracket bonding parts
8
12
electronic control box assembly of
Air-cooled module
1
43
Motor mounting plate welded
4
12.1
Outdoor control board assembly
2
44
Three-phase asynchronous motor
4
12.2
AC contactor
4
45
Axial fan
4
12.3
AC contactor
4
46
Condenser fixed plate ass'y of unit
B
2
12.4
Transformer
1
47
Unit B condenser parts
2
12.5
Transformer
1
47.1
Condenser ass'y of unit B
1
12.6
Current transformer
4
47.2
B-flute-shaped tube assemblies
1
12.7
7-terminal Block
1
47.3
Distributor ass'y of unit B
condenser
1
12.8
Wire joint(4P)
1
48
Evaporator connection pipe ass'y
of unit A1 of four-way valve
1
12.9
Terminal block
6
48.1
Pressure controller
1
12.10
Terminal block
1
49
Four-way valve ass'y of unit B2
1
13
Cover plate of electric control box
1
49.1
Four-way valve
1
14
Cover
1
49.2
Pressure controller
1
15
Cover
1
49.3
Meter connector
2
16
Cover
1
50
Evaporator connection pipe ass'y
of unit B2 of four-way valve
1
17
Welded parts of base
1
50.1
Pressure controller
1
18
Compressor
4
51
Suction pipe ass'y of unit A2
1
19
Storage tank bottom II weld
installation
1
51.1
Pressure controller
1
20
Compressor installed base II weld
1
52
Suction pipe ass'y of unit B1
3
21
Reinforcement board
4
52.1
Pressure controller
1
22
Triangle reinforcement ass'y
8
53
Four-way valve ass'y of unit A2
1
23
Piping support-unit
2
53.1
Sleeve of temp. sensor
1
24
Vapor-liquid separator
4
53.2
Pressure controller
1
25
Shell and tube evaporator
1
53.3
Pressure controller
1
26
Storage tank bottom I weld parts
installation
1
53.4
Meter connector
2
27
Compressor installed base I weld
1
54
I sealed connector condenser
2
28
Vertical beams in the frame
2
55
Roof rack beams II
1
29
I left panel
3
56
Top cover
4
30
Evaporator inlet pipe ass'y of unit B2
1
57
I beam roof rack
1
30.1
Electronic expansion valve
1
58
Vertical beam roof rack
2
31
Inlet pipe ass'y of unit A2 evaporator
1
59
Total water temp. sensor ass'y
1
