DM12-01.01.10en Oasis Inverter
Service manual 35
10. Electronic function
10.1 Abbreviation
T1: Indoor room temperature
T2: Coil temperature of evaporator
T3: Coil temperature of condenser
T4: Outdoor ambient temperature
T5: Compressor discharge temperature
10.2 Display function
10.2.1 Icon explanation on indoor display board.
FRESH indication lamp: This lamp illuminates when Clean Air feature is activated.
DEFROST indication lamp: Lights up when the air conditioner starts defrosting
automatically or when the warm air control feature is activated in heating operation.
RUN indication lamp：This lamp illuminates when the air conditioner is in operation.
TIMER indication lamp：Lights up during Timer operation.
Temperature indicator：Displays the temperature settings when the air conditioner
is operational. Displays the malfunction code.
