8 Service manual
3. Specification
Indoor
MS11MU-09HRDN1 MS11MU-12HRDN1
Outdoor
MO11MU-09HRDN1 MO11MU-12HRDN1
Powersupply Ph‐V‐Hz
220-240V~ 50Hz, 1Ph 220-240V~ 50Hz, 1Ph
Cooling
Capacity
Btu/h
9000(2050~11800) 12000(4000~14200)
kW
2,64 (0,60 - 3,46) 3,52 (1,17 - 4,16)
Input W
820(230~1120) 1090(350~1220)
Ratedcurrent A
3.8(1.0~4.7) 4.8(1.5~5.0)
EER W/W
3.22 3.23
Heating
Capacity
Btu/h
10000(3200~13800) 13000(4100~15100)
kW
2,93 (0,94 - 4,04) 3,81 (1,20 - 4,43)
Input W
810(230~1010) 1050(350~1150)
Ratedcurrent A
3.7(1.0~4.2) 4.6(1.5~4.8)
COP W/W
3.62 3.63
MoistureRemoval L/h
1.0 1.2
Max.inputconsumption W
1850 1850
Max.current A
8.5 8.5
Startingcurrent A
---- ----
Compressor
Model 
DA108X1C-23EZ DA108X1C-23EZ
Type 
ROTARY ROTARY
Brand 
TOSHIBA TOSHIBA
Capacity Btu/h
11021 11021
Input W
855 855
Ratedcurrent(RLA) A
4.95 4.95
LockedrotorAmp(LRA) A
---- ----
Thermalprotector 
---- ----
Thermalprotector
position

---- ----
Capacitor uF
6.0 6.0
Refrigerantoil/oil
charge
ml
ESTER OIL VG74 480ml ESTER OIL VG74 480ml
Indoorfan
motor
Model 
RPG13H RPG20D
Brand 
Welling Welling
Input W
34 43.3
Capacitor
uF
1.2 1.5
Speed(Hi/Mi/Lo) r/min
1200 / 1000 / 700 1220 / 1000 / 800
Indoorcoil
a.Numberofrows 
2 2
b.Tubepitch(a)xrow
pitch(b)
mm
21x13.37 21x13.37
c.Finspacing mm
1.3 1.3
d.Fintype(code) 
Hydrophilic aluminium Hydrophilic aluminium
e.Tubeoutsidedia.and
type
mm
7, innergroove tube 7,innergroove tube
f.Coillengthxheightx mm
580x252x26.74 655x315x26.74

Midea MO11MU-09HRDN1 Specifications

General

Brand	Midea
Model	MO11MU-09HRDN1
Category	Air Conditioner
Language	English
