DM12-01.01.10en Oasis Inverter
Service manual 9
width
g.Numberofcircuits 
2 4
Indoorairflow(Hi/Mi/Lo) m
3
/h
600/500/350 700/570/460
Indoornoiselevel(Hi/Mi/Lo) dB(A)
40/36/27 42/37/31
Indoorunit
Dimension(W*D*H) mm
750x280x198 835x280x198
Packing(W*D*H) mm
830x270x355 910x270x355
Net/Grossweight Kg
8 / 10 9 / 11
Outdoorfan
motor
Model 
YDK24-6P(B) YDK24-6P(B)
Brand 
Welling Welling
Input W
60/50 60/50
Capacitor
uF
2.5 2.5
Speed r/min
860 / -- / 660 860 / -- / 660
Outdoorcoil
a.Numberofrows 
1.6 2
b.Tubepitch(a)xrow
pitch(b)
mm
21x13.37 21x13.37
c.Finspacing mm
1.4 1.4
d.Fintype(code) 
Hydrophilic aluminium Hydrophilic aluminium
e.Tubeoutsidedia.and
type
mm
7,innergroove tube 7,innergroove tube
f.Coillengthxheightx
width
mm
720x504x13.37+419x504x13.3
7
720x504x26.74
g.Numberofcircuits 
4 2
Outdoorairflow m
3
/h
1600 1600
Outdoornoiselevel dB(A)
54 55
Outdoorunit
Dimension(W*D*H) mm
670x265x540 670x265x540
Packing(W*D*H) mm
770x325x570 770x325x570
Net/Grossweight Kg
27 / 29 29 / 31
Refrigeranttype g
R410A/870g R410A/980g
Designpressure MPa
4.2/1.5 4.2/1.5
Refrigerant
piping
Liquidside/Gasside
mm
(inch)
6.35/9.52(1/4"/3/8") 6.35/9.52(1/4"/3/8")
Max.refrigerantpipe
length
m
20 20
Max.differenceinlevel m
8 8
Connectionwiring 
1.5(Optional) 1.5(Optional)
Plugtype 
-- --
Thermostattype 
Remote Control Remote Control
Operationtemp
℃
17-30 17-30
Ambienttemp(cooling/heating)
℃
0-50/-15-34 0-50/-15-34
Applicationarea m
2

13-22 18-29
