Midea MO11MU-09HRDN1

Oasis Inverter DM12-01.01.10en
10 Service manual
Indoor
MS11MU-18HRDN1 MS11MU-24HRDN1
Outdoor
MO11MU-18HRDN1 MO11MU-24HRDN1
Powersupply Ph‐V‐Hz
220-240V~ 50Hz, 1Ph 220-240V~ 50Hz, 1Ph
Cooling
Capacity
Btu/h
18000(5000~19000) 24000(12000~26000)
kW
5,28 (1,47 - 5,57) 7,03 (3,52 - 7,62)
Input W
1545(600~1750) 2190(800~2700)
Ratedcurrent A
6.8(1.7~7.6) 9.5(3.5~11.7)
EER W/W
3.41 3.21
Heating
Capacity
Btu/h
19000(5000~20000) 25000(12000~27000)
kW
5,57 (1,47 - 5,86) 7,33 (3,52 - 7,91)
Input W
1510(600~1700) 2030(800~2750)
Ratedcurrent A
6.7(1.5~7.4) 8.8(3.5~12.0)
COP W/W
3.69 3.61
MoistureRemoval L/h
1.8 2.6
Max.inputconsumption W
2640 3050
Max.current A
11.9 14.0
Startingcurrent A
---- ----
Compressor
Model 
DA130S1C-20FZ DA150S1C-20FZ
Type 
ROTARY ROTARY
Brand 
GMCC GMCC
Capacity Btu/h
13170 15286
Input W
990 1150
Ratedcurrent(RLA) A
4.97 9.7
LockedrotorAmp(LRA) A
---- ----
Thermalprotector 
1NT01L-4639 or KSD301 KSD301
Thermalprotector
position

---- EXTERNAL
Capacitor uF
45 50
Refrigerantoil/oilcharge ml
ESTER OIL VG74/500 ESTER OIL VG74/500
Indoorfan
motor
Model 
RPG45C RPG50C
Brand 
Broad Ocean Broad Ocean
Input W
72 91
Capacitor
uF
3.0 3.5
Speed(Hi/Mi/Lo) r/min
1200 / 900 / 700 1250 / 1100 / 800
Indoorcoil
a.Numberofrows 
2 2
b.Tubepitch(a)xrow
pitch(b)
mm
21x13.37 21x13.37
c.Finspacing mm
1.3 1.3
d.Fintype(code) 
Hydrophilic aluminium Hydrophilic aluminium
e.Tubeoutsidedia.and
type
mm
7,innergroove tube 7,innergroove tube
f.Coillengthxheightx
width
mm
760x315x26.74 904x399x26.74
g.Numberofcircuits 
5 5
Indoorairflow(Hi/Mi/Lo) m
3
/h
1150/860/670 1550/1350/1000
