Midea MO11MU-09HRDN1 User Manual

DM12-01.01.10en Oasis Inverter
Service manual 11
Indoornoiselevel(Hi/Mi/Lo) dB(A)
48/38/32 50/47/39
Indoorunit
Dimension(W*D*H) mm
990x315x218 1186x340x258
Packing(W*D*H) mm
1065x300x400 1265x420x340
Net/Grossweight Kg
12 / 14 16 / 20
Outdoorfan
motor
Model 
YDK24-6G YDK55-6G
Brand 
Welling Board-ocean
Input W
67/48 103/78
Capacitor
uF
2.5 2.5
Speed r/min
800/550 865 / -- / 670
Outdoorcoil
a.Numberofrows 
2 2.5
b.Tubepitch(a)xrow
pitch(b)
mm
21x13.37 21x13.37
c.Finspacing mm
1.4 1.4
d.Fintype(code) 
Hydrophilic aluminium Hydrophilic aluminium
e.Tubeoutsidedia.and
type
mm
7,innergroove tube 7,innergroove tube
f.Coillengthxheightx
width
mm
655x546x26.74
779x651x26.74+
390x651x13.37
g.Numberofcircuits 
3 6
Outdoorairflow m
3
/h
2200 2700
Outdoornoiselevel dB(A)
56 59
Outdoorunit
Dimension(W*D*H) mm
760x285x590 845x320x700
Packing(W*D*H) mm
887x355x645 965x395x755
Net/Grossweight Kg
36.5 / 39 49.5 / 52.5
Refrigeranttype g
R410A/1150g R410A/1980g
Designpressure MPa
4.2/1.5 4.2/1.5
Refrigerant
piping
Liquidside/Gasside
mm
(inch)
6.35/12.7(1/4"/1/2") 9.52/16(3/8"/5/8")
Max.refrigerantpipe
length
m
20 25
Max.differenceinlevel m
8 10
Connectionwiring 
1.5(Optional) 1.5(Optional)
Plugtype 
-- --
Thermostattype 
Remote Control Remote Control
Operationtemp
℃
17-30 17-30
Ambienttemp(cooling/heating)
℃
0-50/-15-34 0-50/-15-34
Applicationarea m
2

25-42 35-58
