3. Specification
Code
2T0032300361
2T0032500279
Indoor code
220032304710
220032503610
Outdoor code
220037303660
220037503660
Indoor model
MSV1-09HRFN1-MT0W
MSV1-12HRFN1- MT0W
Outdoor model
MOC-09HFN1-MT0W
MOC-12HFN1-MT0W
Power supply
Ph-V-Hz
1Ph, 208-230V～, 60Hz
1Ph, 208-230V～, 60Hz
MINIMUM CIRCUIT AMPACITY
A
15
15
MAX.FUSE
A
20
20
Moisture removal
L/h
1.0
1.2
Compressor
Model
DA108X1C-20FZ3
DA108X1C-20FZ3
Type
ROTARY
ROTARY
Brand
GMCC
GMCC
Capacity
Btu/h
10918
10918
Input
W
855
855
Rated current(RLA)
A
5.3
5.3
Locked rotor Amp(LRA)
A
10
10
Thermal protector
INT01L-4639 / CS-74
INT01L-4639 / CS-74
Thermal protector position
EXTERNAL
EXTERNAL
Capacitor
uF
35
35
Refrigerant oil/oil charge
ml
ESTER OIL VG74 / 480
ESTER OIL VG74 / 480
Indoor fan motor
Model
WZDK20-38G
WZDK20-38G
Brand
Panasonic
Panasonic
Input
W
20(Output )
20(Output )
RLA
A
0.06
0.06
LRA
A
/
/
Winding Resistance
Ω
/
/
Capacitor
uF
----
----
Speed(Hi/Mi/Lo)
r/min
1250/1000/900
1250/1000/900
Indoor unit
Dimension(W*D*H)
mm
845x165x286
845x165x286
Dimension(W*D*H)
inch
33.27x6.50x11.26
33.27x6.50x11.26
Packing (W*D*H)
mm
905x285x355
905x285x355
Packing (W*D*H)
inch
35.63x11.22x13.98
35.63x11.22x13.98
Net/Gross weight
Kg
9/11
9/11
Net/Gross weight
lbs.
19.84/24.25
19.84/24.25
Outdoor fan motor
Model
WZDK35-38G
WZDK35-38G
Brand
Panasonic
Panasonic
Input
W
35(Output )
35(Output )
RLA
A
0.15
0.15
LRA
A
/
/
Winding Resistance
Ω
/
/
Capacitor
uF
----
----
